SLV TRACK SYSTEMS | 4 For sophisticated technical projects: You can master any lighting design challenge by using lots of track elements that can be freely combined. CONTENTS
SLV TRACK SYSTEMS | 5 CONTENTS SLV S-TRACK SYSTEM 3-phase surface-mounted track and accessories 6 – 9 3-PHASE LIGHTS NUMINOS® S, M, L 10–15 NUMINOS® S, M, L DALI 16–21 SIGHT MOVE DALI 22–23 SIGHT TRACK DALI 24–25 ONE 40 TRACK DALI 26–27 EUTRAC® SYSTEM 3-phase surface-mounted track and accessories 28–31 EUTRAC® SYSTEM 3-phase recessed track and accessories 32–33 COMPATIBILITY 3-phase busbars 34–35 NUMINOS® CONFIGURATOR Configure spots online 36–37 SYMBOL KEY 39 CONTENTS
SLV TRACK SYSTEMS | 6 S-TRACK
SLV TRACK SYSTEMS | 7 S-TRACK S-TRACK 3-phase surface-mounted track Your professional track The S-TRACK 3-phase busbars are ideal for shops, museums, hotels and restaurants. The large number of powerful spotlights allow a wide variety of lighting scenarios that can be controlled on separate electrical circuits. • A large selection of powerful spotlights • Separately controlled electrical circuits • Relatively independent from power outlet points • Scalability thanks to many track elements • Compatible with DALI smart lighting projects 1 m 1 m 2 m 2 m Nominal voltage (V) 220-240 V ~50/60 Hz 220-240 V ~50/60 Hz 220-240 V ~50/60 Hz 220-240 V ~50/60 Hz Max. current (A) 16 16 16 16 Max. mech. load 30 kg 30 kg 30 kg 30 kg Material aluminium aluminium aluminium aluminium Colour black white black white L x W x H (cm) 100 x 3.6 x 3.6 100 x 3.6 x 3.6 200 x 3.6 x 3.6 200 x 3.6 x 3.6 Weight (kg) 0.9 0.9 1.84 1.84 Prod. no. 1004937 1004938 1002631 1002632 3 m 3 m 4 m 4 m Nominal voltage (V) 220-240 V ~50/60 Hz 220-240 V ~50/60 Hz 220-240 V ~50/60 Hz 220-240 V ~50/60 Hz Max. current (A) 16 16 16 16 Max. mech. load 30 kg 30 kg 30 kg 30 kg Material aluminium aluminium aluminium aluminium Colour black white black white L x W x H (cm) 300 x 3.6 x 3.6 300 x 3.6 x 3.6 400 x 3.6 x 3.6 400 x 3.6 x 3.6 Weight (kg) 2.76 2.76 3.53 3.53 Prod. no. 1002633 1002634 1002635 1002636
1002637 1002639 1002638 1002640 1002647 1002649 1002648 1002650 1002651 1002653 1002652 1002654 1002655 1002656 1001380 175060/64 1002648 1002650 1002648 1002650 1002648 1002650 1002648 1002650 1002648 1002650 1002655 1002656 1002643 1002644 1002643 1002644 1002647 1002649 1002647 1002649 1002647 1002649 1004941 1004942 1004943 1004944 1004941 1004942 1002637 1002639 1004943 1004944 S-TRACK 3-phase DALI surface-mounted track Planning assistance and accessories at a glance View of components from above on the installation side
SLV TRACK SYSTEMS | 9 S-TRACK Feed, DALI, earth left Max. 10 A | polycarbonate (PC) L: 13.9 cm W: 3.5 cm H: 3.3 cm black Prod. no. 1002637 white Prod. no. 1002639 Feed, DALI, earth right Max. 16 A | polycarbonate (PC) L: 13.9 cm W: 3.5 cm H: 3.3 cm black Prod. no. 1002638 white Prod. no. 1002640 Feed, DALI, earth external Max. 16 A | polycarbonate (PC) L: 11.9 cm W: 11.9 cm H: 3.3 cm black Prod. no. 1002647 white Prod. no. 1002649 Feed, DALI, earth internal Max. 16 A | polycarbonate (PC) L: 11.9 cm W: 11.9 cm H: 3.3 cm black Prod. no. 1002648 white Prod. no. 1002650 T-connector, DALI, earth external, left* Max. 16 A | polycarbonate (PC) L: 20.3 cm W: 11.9 cm H: 3.3 cm black Prod. no. 1002652 white Prod. no. 1002654 T-connector, DALI, earth external, right* Max. 16 A | polycarbonate (PC) L: 20.3 cm W: 11.9 cm H: 3.3 cm black Prod. no. 1002651 white Prod. no. 1002653 T-connector, DALI, earth internal, left* Max. 16 A | polycarbonate (PC) L: 20.3 cm W: 11.9 cm H: 3.3 cm black Prod. no. 1004941 white Prod. no. 1004942 T-connector, DALI, earth internal, right* Max. 16 A | polycarbonate (PC) L: 20.3 cm W: 11.9 cm H: 3.3 cm black Prod. no. 1004943 white Prod. no. 1004944 X-connector, DALI* Max. 16 A | polycarbonate (PC) L: 20.3 cm W: 20.3 cm H: 3.3 cm black Prod. no. 1002655 white Prod. no. 1002656 Longitudinal connector, DALI Max. 16 A | polycarbonate (PC) L: 10.6 cm W: 2.5 cm H: 2.8 cm black Prod. no. 1002641 white Prod. no. 1002642 Longitudinal connector, DALI* Max. 10 A | polycarbonate (PC) L: 20.3 cm W: 3.5 cm H: 3.3 cm black Prod. no. 1002643 white Prod. no. 1002644 Flexible connector, DALI Max. 16 A | polycarbonate (PC) L: 28.5 cm W: 3.5 cm H: 3.3 cm black Prod. no. 1002645 white Prod. no. 1002646 Insulating connector Polycarbonate (PC) L: 6.8 cm W: 3.1 cm H: 2.6 cm black Prod. no. 175080 white Prod. no. 1001382 Mounting bracket Steel L: 4 cm W: 3.4 cm H: 1.25 cm black Prod. no. 1002657 white Prod. no. 1002658 3-phase adapter, DALI Max. 10 A | polycarbonate (PC) L: 11.3 cm W: 5.5 cm H: 3.3 cm black Prod. no. 1002660 white Prod. no. 1002659 Mech. 3-phase adapter Aluminium / polycarbonate (PC) L: 6.6 cm W: 6.6 cm H: 3.1 cm black Prod. no. 175210 white Prod. no. 1001395 Cover Polycarbonate (PC) L: 200 cm W: 2.2 cm H: 0.75 cm black Prod. no. 1004939 white Prod. no. 1004940 End cap Polycarbonate (PC) L: 3.5 cm W: 3.3 cm H: 3.2 cm black Prod. no. 175060 white Prod. no. 1001380 Pendant suspension Aluminium / polycarbonate (PC) L: 6 cm W: 6 cm H: 4 cm | max. 10 kg black Prod. no. 175160 white Prod. no. 1001390 Joint connector Aluminium L: 18.2 cm W: 3.3 cm H: 2.1 cm black Prod. no. 175180 white Prod. no. 1001392 Hook Polycarbonate (PC) / steel H: 5.2 cm diameter: 2.6 cm | max. 10 kg black Prod. no. 175190 white Prod. no. 1001393 Ceiling rose Max. 16 A | polycarbonate (PC) H: 3.56 cm diameter: 14.32 cm black Prod. no. 1004684 white Prod. no. 1004685 Wire rope suspension, 2-piece Stainless steel / brass L: 500 cm | max. 10 kg nickel Prod. no. 1002845 * with feed capability
Available with different luminous flux, colour temperatures and beam angles Can be pivoted 90° and rotated 350°
SLV TRACK SYSTEMS | 11 NUMINOS® S NUMINOS® S black Colour temperature (K) 2700 K 2700 K 2700 K 3000 K 3000 K 3000 K 4000 K 4000 K 4000 K Luminous flux (lm) 985 lm 985 lm 980 lm 1020 lm 1020 lm 1020 lm 1100 lm 1100 lm 1100 lm Angle 24° 36° 60° 24° 36° 60° 24° 36° 60° Prod. no. 1004074 1004075 1004076 1004082 1004083 1004084 1004090 1004091 1004092 white Colour temperature (K) 2700 K 2700 K 2700 K 3000 K 3000 K 3000 K 4000 K 4000 K 4000 K Luminous flux (lm) 985 lm 985 lm 980 lm 1020 lm 1020 lm 1020 lm 1100 lm 1100 lm 1100 lm Angle 24° 36° 60° 24° 36° 60° 24° 36° 60° Prod. no. 1004078 1004079 1004080 1004086 1004087 1004088 1004094 1004095 1004096 Nominal voltage (V) 220-240 V ~50/60 Hz | 250 mA System output (W) 11 CRI 90 Material aluminium / plastic L / diameter / H (cm) 16.2 / 6.5 / 14.5 50000 350° 90° 0,53
The ideal power class for medium-sized shops and offices Can be pivoted 90° and rotated 350°
SLV TRACK SYSTEMS | 13 NUMINOS® M NUMINOS® M black Colour temperature (K) 2700 K 2700 K 2700 K 3000 K 3000 K 3000 K 4000 K 4000 K 4000 K Luminous flux (lm) 1925 lm 1935 lm 1885 lm 1955 lm 1970 lm 1880 lm 2125 lm 2120 lm 2060 lm Angle 24° 36° 60° 24° 36° 60° 24° 36° 60° Prod. no. 1004170 1004171 1004172 1004178 1004179 1004180 1004186 1004187 1004188 white Colour temperature (K) 2700 K 2700 K 2700 K 3000 K 3000 K 3000 K 4000 K 4000 K 4000 K Luminous flux (lm) 1925 lm 1935 lm 1885 lm 1955 lm 1970 lm 1880 lm 2125 lm 2120 lm 2060 lm Angle 24° 36° 60° 24° 36° 60° 24° 36° 60° Prod. no. 1004174 1004175 1004176 1004182 1004183 1004184 1004190 1004191 1004192 Nominal voltage (V) 220-240 V ~50/60 Hz | 500 mA System output (W) 20 CRI 90 Material aluminium / plastic L / diameter / H (cm) 18.5 / 8.5 / 16.5 50000 350° 90° 0,72
The highest power class for large shops and spaces Can be pivoted 90° and rotated 350°
SLV TRACK SYSTEMS | 15 NUMINOS® L NUMINOS® L black Colour temperature (K) 2700 K 2700 K 2700 K 3000 K 3000 K 3000 K 4000 K 4000 K 4000 K Luminous flux (lm) 2440 lm 2400 lm 2475 lm 2430 lm 2340 lm 2400 lm 2675 lm 2620 lm 2715 lm Angle 24° 36° 60° 24° 36° 60° 24° 36° 60° Prod. no. 1004266 1004267 1004268 1004274 1004275 1004276 1004282 1004283 1004284 white Colour temperature (K) 2700 K 2700 K 2700 K 3000 K 3000 K 3000 K 4000 K 4000 K 4000 K Luminous flux (lm) 2440 lm 2400 lm 2475 lm 2430 lm 2340 lm 2400 lm 2675 lm 2620 lm 2715 lm Angle 24° 36° 60° 24° 36° 60° 24° 36° 60° Prod. no. 1004270 1004271 1004272 1004278 1004279 1004280 1004286 1004287 1004288 Nominal voltage (V) 220-240 V ~50/60 Hz | 700 mA System output (W) 28 CRI 90 Material aluminium / plastic L / diameter / H (cm) 21.3 / 10 / 18 50000 350° 90° 1
The smallest power class for DALI-controlled light Can be pivoted 90° and rotated 350°
SLV TRACK SYSTEMS | 17 NUMINOS® S DALI NUMINOS® S black Colour temperature (K) 2700 K 2700 K 2700 K 3000 K 3000 K 3000 K 4000 K 4000 K 4000 K Luminous flux (lm) 985 lm 985 lm 980 lm 1020 lm 1020 lm 1020 lm 1100 lm 1100 lm 1100 lm Angle 24° 36° 60° 24° 36° 60° 24° 36° 60° Prod. no. 1004362 1004363 1004364 1004370 1004371 1004372 1004378 1004379 1004380 white Colour temperature (K) 2700 K 2700 K 2700 K 3000 K 3000 K 3000 K 4000 K 4000 K 4000 K Luminous flux (lm) 985 lm 985 lm 980 lm 1020 lm 1020 lm 1020 lm 1100 lm 1100 lm 1100 lm Angle 24° 36° 60° 24° 36° 60° 24° 36° 60° Prod. no. 1004366 1004367 1004368 1004374 1004375 1004376 1004382 1004383 1004384 Nominal voltage (V) 220-240 V ~50/60 Hz | 250 mA System output (W) 11 CRI 90 Material aluminium / plastic L / diameter / H (cm) 16.2 / 6.5 / 14.5 50000 350° 90° 0,53
The medium power class for DALI-controlled light Can be pivoted 90° and rotated 350°
SLV TRACK SYSTEMS | 19 NUMINOS® M DALI NUMINOS® M black Colour temperature (K) 2700 K 2700 K 2700 K 3000 K 3000 K 3000 K 4000 K 4000 K 4000 K Luminous flux (lm) 1925 lm 1935 lm 1885 lm 1955 lm 1970 lm 1880 lm 2125 lm 2120 lm 2060 lm Angle 24° 36° 60° 24° 36° 60° 24° 36° 60° Prod. no. 1004458 1004459 1004460 1004466 1004467 1004468 1004474 1004475 1004476 white Colour temperature (K) 2700 K 2700 K 2700 K 3000 K 3000 K 3000 K 4000 K 4000 K 4000 K Luminous flux (lm) 1925 lm 1935 lm 1885 lm 1955 lm 1970 lm 1880 lm 2125 lm 2120 lm 2060 lm Angle 24° 36° 60° 24° 36° 60° 24° 36° 60° Prod. no. 1004462 1004463 1004464 1004470 1004471 1004472 1004478 1004479 1004480 Nominal voltage (V) 220-240 V ~50/60 Hz | 500 mA System output (W) 20 CRI 90 Material aluminium / plastic L / diameter / H (cm) 18.5 / 8.5 / 16.5 50000 350° 90° 0,72
The largest power class for DALI-controlled light Can be pivoted 90° and rotated 350°
SLV TRACK SYSTEMS | 21 NUMINOS® L DALI NUMINOS® L black Colour temperature (K) 2700 K 2700 K 2700 K 3000 K 3000 K 3000 K 4000 K 4000 K 4000 K Luminous flux (lm) 2440 lm 2400 lm 2475 lm 2430 lm 2340 lm 2400 lm 2675 lm 2620 lm 2715 lm Angle 24° 36° 60° 24° 36° 60° 24° 36° 60° Prod. no. 1004554 1004555 1004556 1004562 1004563 1004564 1004570 1004571 1004572 white Colour temperature (K) 2700 K 2700 K 2700 K 3000 K 3000 K 3000 K 4000 K 4000 K 4000 K Luminous flux (lm) 2440 lm 2400 lm 2475 lm 2430 lm 2340 lm 2400 lm 2675 lm 2620 lm 2715 lm Angle 24° 36° 60° 24° 36° 60° 24° 36° 60° Prod. no. 1004558 1004559 1004560 1004566 1004567 1004568 1004574 1004575 1004576 Nominal voltage (V) 220-240 V ~50/60 Hz | 700 mA System output (W) 28 CRI 90 Material aluminium / plastic L / diameter / H (cm) 21.3 / 10 / 18 50000 350° 90° 1
Ideal for basic lighting in offices and shops Can be pivoted 120°
SLV TRACK SYSTEMS | 23 SIGHT MOVE DALI SIGHT MOVE black white Colour temperature (K) 3000 K 4000 K 3000 K 4000 K Luminous flux (lm) 2700 lm 3100 lm 2700 lm 3100 lm Prod. no. 1004690 1004692 1004691 1004693 Nominal voltage (V) 220-240 V ~50/60 Hz | 350 mA System output (W) 26 CRI 90 Material aluminium / polymethyl methacrylate (PMMA) L / W / H (cm) 45 / 5.6 / 10.5 LED IP 20 75° L70B50 120° 1,24
Ideal for basic lighting in offices and shops CCT switch
SLV TRACK SYSTEMS | 25 SIGHT TRACK DALI SIGHT TRACK black white Colour temperature (K) 3000 K / 4000 K 3000 K / 4000 K Luminous flux (lm) 3000 lm / 3000 lm 3000 lm / 3000 lm Prod. no. 1005397 1005399 Nominal voltage (V) 220-240 V ~50/60 Hz | 700 mA System output (W) 39 CRI 90 Material aluminium / acrylic L / W / H (cm) 114 / 4.5 / 12 LED IP20 50000 120° 2
Creates indirect lighting Can be pivoted 100° and rotated 340°
SLV TRACK SYSTEMS | 27 ONE 40 TRACK DALI ONE 40 TRACK black white Colour temperature (K) 3000 K 4000 K 3000 K 4000 K Luminous flux (lm) 650 lm 670 lm 650 lm 670 lm Prod. no. 1004769 1004771 1004770 1004772 Nominal voltage (V) 220-240 V ~50/60 Hz | 350 mA System output (W) 15.2 CRI 90 Material aluminium Diameter / H (cm) 40 / 10.5 IP20 340° 100° 170° 0,75
SLV TRACK SYSTEMS | 28 EUTRAC®
SLV TRACK SYSTEMS | 29 EUTRAC® EUTRAC® 3-phase surface-mounted track Standard requirements? If you are looking for a proven track system or the bid you are working on requires one, the aluminium support track on the EUTRAC® high-voltage 3-phase track system is compatible with SLV lights. The surface-mounted version is available in several colours and lengths. 1 m 1 m 1 m 2 m 2 m 2 m Nominal voltage (V) 220-240 V ~50/60 Hz 220-240 V ~50/60 Hz 220-240 V ~50/60 Hz 220-240 V ~50/60 Hz 220-240 V ~50/60 Hz 220-240 V ~50/60 Hz Max. current (A) 16 16 16 16 16 16 Material aluminium / polycarbonate (PC) aluminium / polycarbonate (PC) aluminium / polycarbonate (PC) aluminium / polycarbonate (PC) aluminium / polycarbonate (PC) aluminium / polycarbonate (PC) Colour black white grey black white grey L x W x H (cm) 100 x 3.6 x 3.2 100 x 3.6 x 3.2 100 x 3.6 x 3.2 200 x 3.6 x 3.2 200 x 3.6 x 3.2 200 x 3.6 x 3.2 Weight (kg) 1.0 1.0 1.0 2.0 2.0 2.0 Prod. no. 145100 1001510 145102 145200 1001511 145202 Manufacturer: EUTRAC® Stromschienen GmbH 3 m 3 m 3 m Nominal voltage (V) 220-240 V ~50/60 Hz 220-240 V ~50/60 Hz 220-240 V ~50/60 Hz Max. current (A) 16 16 16 Material aluminium / polycarbonate (PC) aluminium / polycarbonate (PC) aluminium / polycarbonate (PC) Colour black white grey L x W x H (cm) 300 x 3.6 x 3.2 300 x 3.6 x 3.2 300 x 3.6 x 3.2 Weight (kg) 3.0 3.0 3.0 Prod. no. 145300 1001512 145302 Manufacturer: EUTRAC® Stromschienen GmbH
145510 1001513 145514 145520 1001514 145524 145680 1001521 145684 145670 1001520 145674 145640 1001519 145644 145690 1001522 145694 145630 1001518 145634 145510 1001513 145514 145640 1001519 145644 145630 1001518 145634 145670 1001520 145674 145670 1001520 145674 145670 1001520 145674 145510 1001513 145514 145680 1001521 145684 145520 1001514 145524 145690 1001522 145694 145680 1001521 145684 145520 1001514 145524 145680 1001521 145684 145680 1001521 145684 EUTRAC® 3-phase surface-mounted track Planning assistance and accessories at a glance View of components from above on the installation side Example: external earth Example: internal earth
* with feed capability SLV TRACK SYSTEMS | 31 EUTRAC® Feed, earth left Max. 16 A | polycarbonate (PC) L: 11.2 cm W: 3.6 cm H: 3.2 cm black Prod. no. 145510 white Prod. no. 1001513 grey Prod. no. 145514 Joint connector Polycarbonate (PC) L: 10 cm W: 3.6 cm H: 1.9 cm black Prod. no. 145600 white Prod. no. 1001523 grey Prod. no. 145604 Flex connector Max. 16 A | polycarbonate (PC) / steel L: 22 cm W: 3.6 cm H: 3.2 cm black Prod. no. 145580 white Prod. no. 1001524 grey Prod. no. 145584 Feed, earth right Max. 16 A | polycarbonate (PC) L: 11.2 cm W: 3.6 cm H: 3.2 cm black Prod. no. 145520 white Prod. no. 1001514 grey Prod. no. 145524 Outlet Max. 6.3 A | polycarbonate (PC) L: 9.6 cm W: 6.5 cm H: 9 cm black Prod. no. 145700 white Prod. no. 1001525 Central feed Max. 16 A | polycarbonate (PC) L: 13 cm W: 3.6 cm H: 3.6 cm black Prod. no. 145530 white Prod. no. 1001515 grey Prod. no. 145534 3-phase light adapter Max. 10 A | polycarbonate (PC) black Prod. no. 145990 white Prod. no. 1001542 grey Prod. no. 145994 L-connector, earth internal* Max. 16 A | polycarbonate (PC) / steel L: 15 cm W: 15 cm H: 3.2 cm black Prod. no. 145680 white Prod. no. 1001521 grey Prod. no. 145684 L-connector, earth external* Max. 16 A | polycarbonate (PC) / steel L: 15 cm W: 15 cm H: 3.2 cm black Prod. no. 145670 white Prod. no. 1001520 grey Prod. no. 145674 Pendant clip Aluminium L: 5 cm W: 3.6 cm H: 1.9 cm black Prod. no. 145730 white Prod. no. 1001530 grey Prod. no. 145734 Longitudinal connector* Max. 16 A | polycarbonate (PC) / steel L: 26 cm W: 3.6 cm H: 3.2 cm black Prod. no. 145660 white Prod. no. 1001517 grey Prod. no. 145664 Point outlet Max. 16 A | polycarbonate (PC) H: 3.1 cm diameter: 11.9 cm black Prod. no. 145830 white Prod. no. 1001526 grey Prod. no. 145834 Longitudinal connector Max. 16 A | polycarbonate (PC) L: 5.8 cm W: 1.5 cm H: 2.6 cm black Prod. no. 145560 white Prod. no. 1001516 grey Prod. no. 145564 End cap Polycarbonate (PC) L: 3.6 cm W: 1.7 cm H: 3.2 cm black Prod. no. 145590 white Prod. no. 1001527 grey Prod. no. 145594 T-connector, earth internal, left* Max. 16 A | polycarbonate (PC) / steel L: 26 cm W: 18.5 cm H: 3.2 cm black Prod. no. 145630 white Prod. no. 1001518 grey Prod. no. 145634 Pendant suspension Polycarbonate (PC) / steel L: 60 cm H: 63.5 cm diameter: 7 cm black Prod. no. 145720 white Prod. no. 1001529 grey Prod. no. 145724 T-connector, earth internal, right* Max. 16 A | polycarbonate (PC) / steel L: 26 cm W: 18.5 cm H: 3.2 cm black Prod. no. 145640 white Prod. no. 1001519 grey Prod. no. 145644 Pendant suspension Polycarbonate (PC) / steel L: 120 cm H: 122 cm diameter: 7 cm black Prod. no. 145710 white Prod. no. 1001528 grey Prod. no. 145714 X-connector* Max. 16 A | polycarbonate (PC) / steel L: 26 cm W: 26 cm H: 3.2 cm 2 separate power circuits black Prod. no. 145690 white Prod. no. 1001522 grey Prod. no. 145694 Wire rope suspension, 2-piece Stainless steel / brass L: 500 cm | max. 10 kg nickel Prod. no. 1002845
SLV TRACK SYSTEMS | 32 EUTRAC®
SLV TRACK SYSTEMS | 33 EUTRAC® EUTRAC® 3-phase recessed track with suitable accessories For projects with high aesthetic demands: the recessed version of the EUTRAC® high-voltage 3-phase track 2 m 3 m Nominal voltage (V) 220-240 V ~50/60 Hz 220-240 V ~50/60 Hz Max. current (A) 16 16 Material aluminium / polycarbonate (PC) aluminium / polycarbonate (PC) Colour white white L x W x H (cm) 200 x 5.9 x 4.1 300 x 5.9 x 4.1 Recessed W (cm) 4 4 Weight (kg) 2.6 3.9 Prod. no. 1001531 1001532 Manufacturer: EUTRAC® Stromschienen GmbH Feed, earth left Max. 16 A | polycarbonate (PC) / steel L: 12.2 cm W: 6 cm H: 3.4 cm white Prod. no. 1001533 Feed, earth right Max. 16 A | polycarbonate (PC) / steel L: 12.2 cm W: 6 cm H: 3.4 cm white Prod. no. 1001534 Recessed L-connector with feed Max. 16 A | polycarbonate (PC) / steel L: 16 cm W: 16 cm H: 3.2 cm Earth external, with feed capability white Prod. no. 1001536 Recessed L-connector with feed Max. 16 A | polycarbonate (PC) / steel L: 16 cm W: 16 cm H: 3.2 cm Earth internal, with feed capability white Prod. no. 1001537 End cap Polycarbonate (PC) L: 2.7 cm W: 6 cm H: 3.2 cm white Prod. no. 1001538 Longitudinal connector with stabiliser Max. 16 A | polycarbonate (PC) / steel L: 6.2 cm W: 2.5 cm H: 2.7 cm white Prod. no. 1001539 Spring clip Steel L: 2 cm W: 1 cm H: 2.5 cm grey Prod. no. 145551 3-phase light adapter Max. 10 A | polycarbonate (PC) white Prod. no. 1001542
SLV TRACK SYSTEMS | 34 COMPATIBILITY Subject to prior testing using light and track samples But without DALI functionality Details not guaranteed. Technical data and dimensions are subject to change without notice. During the planning phase of the project, check the project using samples to ensure functionality. Compatibility refers only to tracks/lights. Tracks and track components from different manufacturers should not be combined. COMPATIBILITY 3-phase busbars Compatible with lights/adapters from: Tracks and track components S-Track DALI Use SLV Global/Nordic without DALI with DALI Compatible with tracks and track components from: Lights S-Track DALI Use SLV S-TRACK Global/Nordic without DALI with DALI
The SLV track systems and components are highly compatible with lights and adapters from EUTRAC®, Zumtobel, Erco and LTS ONETrack. Subject to prior testing using light and track samples. EUTRAC® Zumtobel Erco LTS ONETrack EUTRAC® Zumtobel Erco LTS ONETrack
Gathering inspiration? Perhaps you have been gathering inspiration on the NUMINOS® website and have arrived at the Configurator via an application scenario? In this case, the optimal technical options will already been configured. NUMINOS® Online configuration – with a system Create your ideal track spot in just a few simple steps – with the SLV NUMINOS® Online Configurator NUMINOS® is a perfectly coordinated lighting system that offers consistent lighting characteristics and modern design for any application. Our Online Configurator will help you to choose between the large range of sizes and diameters, power classes, lens options and beam angles available to identify the perfect spotlight for your projects. In addition to the spots for 3-phase track systems, the NUMINOS® spotlights are also available as swivelling or fixed ceiling spots and pendant lights. Follow this link for the SLV NUMINOS® Online Configurator: www.ks-light.co.uk/numinos-configurators-en
24° 36° 60° SLV TRACK SYSTEMS | 37 NUMINOS® Available in three housing sizes (65x155 mm, 85x175 mm, 100x203 mm) with a high- power LED module in three light colours (2700 K, 3000 K, 4000 K) Choice of lenses with beam angles of 24°, 36° or 60° Thanks to the built-in LED driver (suitable for phase dimming, DALI), all spotlights are suitable for direct connection to 230 V mains voltage NUMINOS® spotlights are available as swivelling or fixed ceiling spots, pendant lights and as spots for 3-phase track systems. SPOTLIGHTS
LED SLV TRACK SYSTEMS | 39 SYMBOL KEY PRODUCT CHARACTERISTICS Information on whether light sources and control units can be replaced by the end customer or qualified individuals without causing permanent damage to the lights · The LED can be replaced by a qualified person. Weight of the product in kilograms (kg) Rotating and pivoting capacity in degrees: · Rotation range · Pivot range Beam angle Describes the beam angle in degrees. The smaller the angle, the more concentrated the light will be. Average lifespan of a lightbulb or light source in hours Preservation of luminous flux Describes how much the luminous flux of an LED decreases during a specified period. A light distribution curve for the relevant product can be sent to you on request. SAFETY DETAILS Protection classes · Protection class I / protective conductor · Protection class II / protection via double or strengthened insulation APPLICATION AREA · ASSEMBLY IP protection rating Indicates the suitability of electrical equipment for different environmental conditions Use exclusively for indoor spaces SPECIAL SYMBOLS Indicates products · with built-in LEDs Connected lighting Indicates smart products that use the following protocols: · DALI Image credits © SLV GmbH, 2021 © Chlorophylle | Adobe Stock SYMBOL KEY
