bluetooth wall controller CASAMBI RTW4NBT230 UP 4-fold, built-in version, Bluetooth control signal output

Bluetooth Push-button Interface CASAMBI RTW4NBT230 UP, 230V Flush-mounted

The Bluetooth push-button interface CASAMBI RTW4NBT230 UP is ideal for installation in flush-mounted wall boxes. With 4 inputs for push-buttons and 1 output, it offers versatile options for controlling scenes, lights, and light colors. Thanks to the freely programmable inputs, up to 4 wall push-buttons can be connected.

Technical Details and Accessories

The push-button interface comes with accessories including connection cables, mounting housing, switches, radio transmitter, and Bluetooth module. The maximum length of the connection cable is 300cm, and the operating voltage is 220-240V~. The product features a dimming function and is suitable for indoor use.

Further Information on Installation and Functionality

Thanks to the CASAMBI app, you can easily configure and control the push-button interface. The range is up to 30 meters, and control is done via Bluetooth at a frequency of 2.4 GHz. The module has an integrated short-circuit protection and an antenna that should not be covered by metal enclosures.

Versatile Applications

The Bluetooth wall controller from Arditi allows for flexible control of various devices and light sources. With a maximum power consumption of 10mA and a connector type of terminal connection, the push-button interface is easy to install and operate. It can be mounted both flush-mounted and with accessories.

Usage and Safety Notes

Please ensure that the push-buttons are insulated according to the supply voltage. The ambient temperature should be between 0 and +55°C. The product is equipped with IP20 protection and is ideal for use in residential and workspaces. Make sure that the maximum cable length of the push-button inputs does not exceed 30cm.
