LED office panel Business Line 1200 UGR<19 2H, IP40, 36W 4000K 4650lm 120°, white RAL 9016, KNX dimmable, CRi >90

ISOLED



Are you a retailer or business customer (commercial/freelancer)? Secure special B2B prices now.

LED Panel Business Line 1200 UGR<19 2H

The LED Panel Business Line 1200 UGR<19 2H is ideal for use in office buildings, shops, or other commercial spaces. Thanks to its low glare factor of <19 and BAP certification, the panel provides pleasant and glare-free lighting.

High light output and good color rendering

With a power of 36W and a light output of 4650lm, the LED panel offers high light output. The color temperature of 4000K provides neutral and pleasant light. The high color rendering index of >90 also ensures a true-to-life representation of illuminated objects.

Robust and durable

The LED panel has an IP40 protection rating, protecting it from dust and small foreign objects. The high-quality workmanship and design in white RAL 9016 make the panel a timeless and elegant lighting element. The ISOLED brand stands for quality and reliability.

Easy control via KNX

Thanks to dimmability via KNX, you can adjust the brightness of the LED panel according to your needs. This allows for flexible and energy-efficient lighting. The simple control via the KNX system makes operation comfortable and user-friendly.

Versatile applications

The LED Panel Business Line 1200 UGR<19 2H is not only suitable for use in office buildings, but also for installation in ceilings in various commercial spaces. With its high light output, good color rendering, and durable construction, it is the ideal lighting solution for a variety of applications.

Colour:
white
Dimension:
L∕ W∕ H: 119,5∕ 29,5∕ 1 cm
Material:
aluminium
Product type:
LED panel
Lamp shape:
square
Application area:
only suitable for indoor use
Field of application:
wall
ceiling
Operating voltage:
180-295 V~
Dimmable:
yes
Dimmability:
KNX
Power consumption:
38,5 W
LED can be replaced :
no
Bulb type:
fixed LED (non interchangeable)
Light colour:
neutral white
Light emission:
diffuse
Light flux:
4650 lm
Light yield:
120,78 lm/W
Colour temperature:
4000 K
Average life span of a bulb in hours:
50000 h
Colour rendering index:
>80 Ra
1B
IK-Rating:
IK05 up to 0.70 Joule
lamp performance:
36 W
Mounting:
recessed mounting
surfaced mounting
Protection class:
1
IP-protection class:
IP40
Product TÜV Rheinland GS tested:
yes
Additional information:
System power: 36W
Accessories:
control gear included
transformer box excluded
mounting set excluded
ambient temperature:
-20 - 40 °C
Energy efficiency category:
D
EPREL No:
806761
Energy consumption:
39 kWh/1.000 h
Article number:
ISO-114304
Brand:
ISOLED
Manufacturer:
ISOLED
Manufacturer information
ISOLED FIAI Handels GmbH, Egerbach 48, 6334, Schwoich, Austria, product-details-service@isoled.shop, www.isoled.shop/details
