LED office panel Professional Line 1200 UGR<19 8H, IP40, 36W 4000K 4550lm 120°, white RAL 9016, KNX dimmable, CRi >90

LED Panel Professional Line 1200 UGR<19 8H, BAP suitable, IP40, 36W 4000K 4550lm 120°, CRi >90, white RAL 9016

The LED panel from ISOLED's Professional Line, with a power of 36W and a luminous flux of 4550lm, offers a high color rendering of >90Ra and a neutral light color of 4000K. With an extremely wide beam angle of over 80°, it is ideal for screen workstations and is BAP suitable.

Technical details and applications

The panel has protection class 1 and is designed for indoor use. With an IP protection rating of IP40, it is protected against the ingress of solid foreign bodies. Installation can be done as both recessed and surface-mounted, and it is TÜV Rheinland certified for safety.

Energy efficiency and environmental friendliness

With an energy efficiency class D and an energy consumption of 39kWh/1,000h, the LED panel is energy-efficient and environmentally friendly. The average lamp lifespan is 50,000 hours, ensuring a long service life and minimizing maintenance efforts.

Accessories and additional information

The delivery includes the operating device, while the mounting kit and transformer box are available separately. The panel features a diffuser lens for uniform light distribution. The operating voltage is between 180-295V~, and the ambient temperature can range from -20 to 40°C.

Flexibility and compatibility

The LED panel is not replaceable, but it is dimmable via KNX. It is equipped with an electronic transformer as the operating device and has a power factor of 0.92. The shape of the luminaire is square and the color of the panel is white (RAL 9016), fitting a modern and timeless design.
