LED office panel UGR<16 Line 625, IP40, 16 light outlets, 36W 3000K 4100lm, white, 1-10V dimmable

ISOLED



Are you a retailer or business customer (commercial/freelancer)? Secure special B2B prices now.

High Quality and Efficiency

The ISOLED LED Panel UGR<16 Line 625 combines high-quality craftsmanship with high energy efficiency. With a power of 36W and a light output of 4100lm, it offers an excellent lighting solution for various applications.

Glare-free Design

Thanks to the UGR<16 value, the LED panel provides glare-free lighting, which is particularly important in office environments or other work areas. The 16 light outlets ensure even light distribution and contribute to a pleasant room climate.

Flexible Dimming Behavior

The LED panel is equipped with an analog 0-10V dimmer, which allows adjusting the brightness as needed. This allows the lighting to be individually adapted to the specific requirements, whether for a relaxed atmosphere or for focused work.

Easy Installation

With an IP40 protection rating, the LED panel is protected against dust and moisture, making it suitable for use in demanding environments. The white surface seamlessly blends into any room design, and the easy installation allows for quick commissioning.

Technical Details

The LED panel has a color temperature of 3000K, which corresponds to a warm white light color. The EAN number 9009377073618 allows for easy identification of the product. Marked with the BAP seal, the LED panel stands for high quality and safety.

Article number:
ISO-114186
Brand:
ISOLED
Energy efficiency category:
D
EPREL No:
805671
Product type:
LED panel
Energy consumption:
36 kWh/1.000 h
Manufacturer:
ISOLED
Operating voltage:
220-240 V~
Dimmable:
yes
Dimmability:
analog 0-10V
Lamp shape:
square
Power consumption:
36 W
Emitting angle:
120 °
LED can be replaced :
no
Bulb type:
fixed LED (non interchangeable)
Light colour:
warm white
Light emission:
diffuse
Light flux:
4100 lm
Light intensity:
1827 cd
Light yield:
114 lm/W
Colour temperature:
3000 K
Average life span of a bulb in hours:
50000 h
Colour rendering index:
>85 Ra
1B
IK-Rating:
IK04 up to 0.50 Joule
Colour:
white
Material:
aluminium
Fitting opening square/rectangular width:
62.00 cm
Fitting opening square/rectangular length:
62.00 cm
Dimension:
L∕ W∕ H: 62∕ 62∕ 4,7 cm
Mounting:
recessed mounting
surfaced mounting
Field of application:
ceiling
Protection class:
1
IP-protection class:
IP40
Application area:
only suitable for indoor use
Additional information:
System power: 36W
Accessories:
control gear incl
transformer box excl
mounting set excl
ambient temperature:
-20 - 40 °C
