LED panel BACKLIGHT LINE 600 for VDU workstation, current constant, dimmable 36W 3800lm 4000K 120° 120° CRI 90-100

ISOLED



Are you a retailer or business customer (commercial/freelancer)? Secure special B2B prices now.

High Quality and Efficiency

The LED Panel BACKLIGHT LINE 600 UGR<19 8H from ISOLED offers excellent color rendering with a color rendering index of over 90Ra. With a power consumption of 36W and a light output of 106lm/W, this panel provides efficient lighting for indoor spaces.

Versatile Applications

With its shape and size of 59.5 x 59.5 cm, this panel is ideal for installation in standard grid ceilings. It can also be used for surface or pendant mounting, making it versatile for various applications.

Glare-free and Uniform Light Distribution

The BACKLIGHT LINE 600 Panel has a beam angle of 120° and offers a diffuse light distribution. This results in glare-free and uniform lighting that is particularly comfortable for the eyes.

Dimmable and Energy-saving

This panel is dimmable and supports phase-cut dimming. With an energy consumption of 36 kWh/1,000 h and an energy efficiency class of E, it is an energy-efficient lighting solution for indoor spaces.

Reliable Technology and High-quality Materials

The LED Panel from ISOLED is equipped with high-quality SMD 2835 LED light sources and features an aluminum housing. With an average lamp lifespan of 50,000 hours and an IP protection rating of IP20, it provides a durable and reliable lighting solution for various applications.

Colour:
white
Dimension:
L∕ W∕ H: 59,5∕ 59,5∕ 3 cm
Material:
aluminium
Product type:
LED panel
Lamp shape:
square
Bulbs in delivery:
yes
Application area:
only suitable for indoor use
Field of application:
ceiling
Operating voltage:
50 V=
Dimmable:
yes
Dimmability:
trailing edge
Power consumption:
36 W
Emitting angle:
120 °
LED can be replaced :
no
Bulb type:
LED
Light colour:
neutral white
Light emission:
diffuse
Light flux:
3800 lm
Light yield:
106 lm/W
Nominal current:
900 mA
Colour temperature:
4000 K
Average life span of a bulb in hours:
50000 h
Colour rendering index:
90-100 Ra
UGR:
< 19
Colour rendering index:
1A
Fitting opening square/rectangular width:
59,5 cm
Fitting opening square/rectangular length:
59,5 cm
Wire/connection lead diameter:
0,75 ² mm
Plug type:
clamping connection
Mounting:
recessed mounting
surfaced mounting
mounting accessories required
IP-protection class:
IP20
Additional information:
Transformer power: 21 VA
Accessories:
control gear included
mounting accessories excluded
dimmer excluded
ambient temperature:
-20 ... +60 °C
Energy efficiency category:
E
EPREL No:
820533
Energy consumption:
36 kWh/1.000 h
Article number:
ISO-115166
Purchasing quantity:
1 piece
Brand:
ISOLED
Manufacturer:
ISOLED
Manufacturer information
ISOLED FIAI Handels GmbH, Egerbach 48, 6334, Schwoich, Austria, product-details-service@isoled.shop, www.isoled.shop/details
