LED panel Business Line 1200 UGR<19 2H, IP40, 36W 4000K 4650lm 120°, white RAL 9016, push/DALI dimmable

ISOLED



Are you a retailer or business customer (commercial/freelancer)? Secure special B2B prices now.

ISOLED LED Panel Business Line 1200 UGR<19 2H

The ISOLED LED Panel Business Line 1200 with a UGR<19 value and 2H certification is the perfect lighting solution for offices, conference rooms, and other workspaces. With a power of 36W and a luminous flux of 4650lm, this panel provides bright and uniform illumination.

Suitable for BAP and IP40 certified

Thanks to its BAP suitability, the LED panel is ideal for screen workstations and provides glare-free lighting. The IP40 certification also guarantees protection against dust and limited water resistance, making this panel versatile for various applications.

High energy efficiency and easy installation

With an energy efficiency class of D and an energy consumption of 39kWh/1,000 h, the LED Panel Business Line 1200 is very energy efficient. Installation can be done either as recessed or surface-mounted, depending on the need and room design.

Technical details and accessories

The panel features DALI dimmability, allowing for individual adjustment. The operating device is included, while accessories such as mounting kit and transformer box are available separately. The dimensions of the panel are 119.5 x 29.5 x 1 cm (L x W x H).

Reliable quality from ISOLED

As a brand of ISOLED, this LED panel represents tested safety and high-quality craftsmanship. With an average lamp lifespan of 50,000 hours and a color rendering index of >80Ra, the panel offers a durable and high-quality lighting solution.

Article number:
ISO-113509
Brand:
ISOLED
Energy efficiency category:
D
EPREL No:
806751
Product type:
LED panel
Energy consumption:
39 kWh/1.000 h
Manufacturer:
ISOLED
Operating voltage:
220-240 V~
Dimmable:
yes
Dimmability:
DALI
Lamp shape:
square
Power consumption:
38,5 W
LED can be replaced :
no
Bulb type:
fixed LED (non interchangeable)
Light colour:
neutral white
Light emission:
diffuse
Light flux:
4650 lm
Light yield:
120,78 lm/W
Nominal current:
850 mA
Colour temperature:
4000 K
Average life span of a bulb in hours:
50000 h
Colour rendering index:
>80 Ra
1B
lamp performance:
36 W
Colour:
white
Material:
aluminium
Fitting opening square/rectangular width:
29,5 cm
Fitting opening square/rectangular length:
119,5 cm
Dimension:
L∕ W∕ H: 119,5∕ 29,5∕ 1 cm
Mounting:
surfaced mounting
recessed mounting
Field of application:
wall
ceiling
Protection class:
1
IP-protection class:
IP20
Product TÜV Rheinland GS tested:
yes
Application area:
only suitable for indoor use
Additional information:
System power: 36W
Accessories:
control gear incl
transformer box excl
mounting set excl
ambient temperature:
-20 - 40 °C
