LED panel Frame 620 (61.5 x 61.5cm), IP40, 40W 4000K 3700lm 120°, illuminated frame, KNX dimmable, CRi >90

ISOLED



Are you a retailer or business customer (commercial/freelancer)? Secure special B2B prices now.

Efficient LED Panel Frame 620 (61.5 x 61.5cm)

The LED Panel Frame 620 from ISOLED is a high-quality lighting product that impresses with a power of 40W and a luminous flux of 3700lm. With a neutral white light color and a color rendering index of over 83Ra, this panel provides excellent lighting in your space.

Versatile Applications

Thanks to the IP40 protection rating, the LED Panel Frame 620 is ideal for use in various indoor spaces. Whether in the office, living room, or other residential areas - this panel provides uniform and pleasant lighting.

Durable and Energy Efficient

With an average lamp lifespan of 30000 hours and an energy consumption of 40kWh/1,000h, the LED Panel Frame 620 is not only durable but also extremely energy efficient. This helps you save energy costs in the long run while also being environmentally friendly.

High-Quality Material and Easy Installation

The LED Panel Frame 620 is made of aluminum and impresses with its high-quality craftsmanship. The installation can be done as either recessed or surface-mounted, depending on your individual requirements. With the included operating device, installation is easy and straightforward.

Technical Details Overview

The LED Panel Frame 620 has an operating voltage of 220-230V and is designed for ceiling installation. With a color temperature of 4000K and a power factor of 0.92, this panel offers a high-quality lighting solution for various applications. Order the LED Panel Frame 620 from ISOLED now and benefit from an efficient and durable lighting solution!

Colour:
white
Material:
aluminium
Product type:
LED panel
Lamp shape:
square
Application area:
only suitable for indoor use
Field of application:
ceiling
Operating voltage:
220-230 V
Dimmable:
yes
Dimmability:
KNX
Power consumption:
40 W
LED can be replaced :
no
Bulb type:
fixed LED (non interchangeable)
Light colour:
neutral white
Light emission:
diffuse
Light flux:
3700 lm
Light yield:
97,37 lm/W
Colour temperature:
4000 K
Average life span of a bulb in hours:
30000 h
Colour rendering index:
>83 Ra
1B
IK-Rating:
IK05 up to 0.70 Joule
lamp performance:
38 W
Mounting:
recessed mounting
surfaced mounting
Protection class:
1
IP-protection class:
IP40
Additional information:
System power: 38W
Accessories:
control gear included
transformer box excluded
mounting set excluded
ambient temperature:
-20 - 40 °C
Energy efficiency category:
E
EPREL No:
820323
Energy consumption:
40 kWh/1.000 h
Article number:
ISO-114312
Brand:
ISOLED
Manufacturer:
ISOLED
Manufacturer information
ISOLED FIAI Handels GmbH, Egerbach 48, 6334, Schwoich, Austria, product-details-service@isoled.shop, www.isoled.shop/details
