LED panel PANEL FRAME 600 for VDU workstation, dimmable 40W 3600lm 4000K 120° 120° CRI 80-89

ISOLED



Are you a retailer or business customer (commercial/freelancer)? Secure special B2B prices now.

LED Panel FRAME 600, IP40, 59.5 x 59.5cm, 40W 4000K 3600lm 120°

The LED Panel FRAME 600 from ISOLED is ideal for indoor use. With a power of 40W and a light color of 4000K, it offers excellent light output of 3600lm and a wide beam angle of 120°.

Modern design and high quality

The square LED panel is encased in an elegant frame and is made of high-quality aluminum. With a size of 59.5 x 59.5 cm, it fits perfectly in standard grid ceilings and can be installed recessed, surface-mounted, or as a pendant light.

Versatile applications

Thanks to its diffuse light distribution and glare-free, homogeneous light output, the LED panel is suitable for use on ceilings and walls. It is dimmable and can be used with various dimming systems to adjust the light intensity individually.

Efficient and durable

With an energy consumption of 40kWh/1,000 hours and an energy efficiency class E, the LED panel is very efficient in operation. The integrated LEDs have an average lifespan of 30,000 hours and provide high-quality light with a color rendering index of 80-89Ra.

Practical accessories and easy installation

The LED panel comes with an external operating device and can be easily connected to the power supply with a screw clamp. The mounting accessories are included, making installation quick and uncomplicated.

Colour:
white
Dimension:
inside-L∕ W∕ H: 59,5∕ 59,5∕ 1,1 cm
outside-L∕ W: 61,5∕ 61,5 cm
Material:
aluminium
Product type:
LED panel
Lamp shape:
square
Bulbs in delivery:
yes
Application area:
only suitable for indoor use
Field of application:
ceiling
wall
Operating voltage:
50 V=
Dimmable:
yes
Dimmability:
trailing edge
Power consumption:
40 W
Emitting angle:
120 °
LED can be replaced :
no
Bulb type:
LED
Light colour:
neutral white
Light emission:
diffuse
Light flux:
3600 lm
Light yield:
95 lm/W
Nominal current:
880-100 mA
Colour temperature:
4000 K
Average life span of a bulb in hours:
30000 h
Colour rendering index:
80-89 Ra
1B
Fitting opening square/rectangular width:
59,5 cm
Fitting opening square/rectangular length:
59,5 cm
Wire/connection lead diameter:
0,75 ² mm
Plug type:
clamping connection
Mounting:
mounting accessories required
surfaced mounting
recessed mounting
IP-protection class:
IP40
Additional information:
Transformer power: 21 VA
Accessories:
control gear included
mounting accessories excluded
dimmer excluded
ambient temperature:
-20 ... +60 °C
Energy efficiency category:
E
EPREL No:
820548
Energy consumption:
40 kWh/1.000 h
Article number:
ISO-115181
Purchasing quantity:
1 piece
Brand:
ISOLED
Manufacturer:
ISOLED
